2022 edition
ISBN #978-3-932414-55-8
NV Charts Reg. 12.3, Windward Islands, Martinique to Grenada
Format: Kombipack Paper / Digital download and App
- 4 Passage Charts
- 8 Coastal Charts & 18 Details
- Charts Paper and Digital
- Digital Details & Photos of Harbors and Anchorages
The NV Charts are characterized by fine contours and easy to distinguish color graduations of the depth lines – turquoise for coral reefs, red for the 2-meter-line and blue for the 5-m-areas.
Presented in a handy, user friendly size, (23½’’ x 16 ½’’, 11.7 x 16.5 folded) a thick plastic envelope protects the charts, enabling them to be easily stored.
The importance of good graphical representation of the topography when sailing in the Caribbean is essential.
Well marked rivers, towns and street plans all help to give a clear overall view of the shoreside facilities of the islands. Red numbered waypoints with coordinates based on WGS 84 enable yachtsmen to navigate using their GPS instruments. Heights and depths are given in the internationally accepted format of meters. Large scale approaches and land contour markings simplify the entrance into anchorages.
Passage Charts
- C0 Caribbean Sea 1: 6,500,000
- C1 Windward Islands 1: 900,000
- C2 Dominica to St. Vincent 1: 500,000
- C3 St. Vincent to Trinidad 1: 500,000
Coastal Charts
- C4 Martinique North 1: 90,000
- C5 Martinique South 1: 90,000
- C6 St. Lucia 1: 90,000
- C7 St. Vincent to Bequia 1: 90,000
- C8 Bequia to Union Island 1: 90,000
- C9 Union Island to Grenada 1: 90,000
- C10 Grenada 1: 90,000
- C11 Barbados 1: 90,000
Detail Charts
- C12 Martinique · Fort de France 1: 30,000
- C13 Martinique · Cul-de-Sac du Marine 1: 20,000
- C14A St. Lucia · Rodney Bay 1: 15,000
- C14B St. Lucia · Port Castries 1: 10.000
- C14C St. Lucia · Marigot Bay 1: 5.500
- C15 St. Vincent · Southwest Coast 1: 15.000
- C16A Canouan · Charlestown Bay 1: 15.000
- C16B Bequia · Admiralty Bay 1: 15.000
- C17A Tobago Cays 1: 30.000
- C17B Union Island · Clifton Harbour 1: 15.000
- C18A Petit St. Vincent 1: 30.000
- C18B West Carriacou 1: 30.000
- C18C Mustique · Britannia Bay 1: 30.000
- C19 Grenada Southwest 1: 30.000
- C20A Grenada · St. Georges Approach 1: 10.000
- C20B Grenada · Mt. Hartmann Bay 1: 15.000
- C20C Barbados · Port St. Charles 1: 5.000
- C20D Barbados · Bridgetown Hbr. 1: 19.000
Legend · General Notes p.22
